EtherCAT:
Short cycle times and high-precision, almost jitter-free synchronisation are its primary characteristics. Its uniform profile enables comprehensive communication with CANopen.
Modbus-TCP:
The simple structured data model is based on a client/server architecture and transfers the data within TCP/IP packages. This makes Modbus fully compatible with conventional Ethernet networks.
Valve terminal type 44 VTSA/45 VTSA-F
- Controlled via fieldbus or control block
- Max. 32 valve positions/max. 32 solenoid coils
- Max. 10 electrical modules
- Digital inputs/outputs
- Analogue inputs/outputs
- Parameterisation of inputs and outputs
- Integrated convenient diagnostics system
- Preventive maintenance concepts - Connecting thread G
Catalogue information for type 44 VTSA
Catalogue information for type 45 VTSA-F
Valve terminal type 32 MPA/33 MPA-F
- Controlled via fieldbus or control block max.
- 64 valve positions/max. 128 solenoid coils
- Digital inputs/outputs
- Analogue inputs/outputs
- Parameterisation of inputs and outputs
- Integrated convenient diagnostics system
- Preventive maintenance concepts
Catalogue information type for 32 MPA
Modular electrical terminal CPX
- Operating mode
- Stand-alone
- With valve terminal type 45 VTSA-F
- With valve terminal type 44 VTSA
- With valve terminal type 33 MPAF
- With valve terminal type 32 MPA
- With valve terminal type 03 Midi/Maxi - Input/output modules
- Digital
- Analogue
Installation system CPI/CTEC
- Complete concept for decentralised machine and system structure
- 4 installation strings per CP interface
- 10 metre line length per string (radius)
- 4 CP modules per string
- 32 inputs and 32 outputs per string.
