The application: clamping metal sheets in the welding equipment
Your objective: precise, repetition accurate positioning for a perfect fit
Our solution: individual clamping systems with intelligent control
Integrated safety: valve terminal VTSA Profisafe
- High data transmission rate, e.g. for real-time critical IO data
- Comprehensive options for diagnostics, parameterisation or configuration
- Safety functions according to ISO13849-1
- Two-channel electrical and pneumatic shutdown
- Safety functions: venting system components, reversing, protection against restart
Sturdy and attractively priced: clamping cylinder DW
New cylinders of the DW series - specially for applications in harsh environments, e.g. for the welding process in the car body shop:
- Hinged joint on bearing cap and piston rod for difficult applications
- Reliable and durable due to integrated end-position cushioning and restrictors at both ends
Ready-to-install solutions tailored to your requirements
Completely assembled, all tubing and wiring fitted, fully tested and documented:
- Control cabinets and mounting plates
- Modules
- Handling systems
- Hall and robot installation plates (HIP/RIP)
Compact, sturdy and exact: pin pulling cylinder DF/DFM
Ideal for perfect positioning in metal sheet processing:
- Position sensing with LED display
- Welding splash-proof
- Protection against rotation: square piston rod or two guide rods
- Optionally with recirculating ball bearing guide or plain-bearing guide
- Various installation variants due to several supply ports and variable mounting options
- Standardised pin mounting for different centring spigots
