Working it out for you: reducedpressureduring the
returnstroke
-22%
6bar
3bar
6bar
6bar
Before
32mm, 500mm 5.1Nl
After
32mm, 500mm 4.0Nl
• Air consumptionof astandard
cylinderDSBC32-500during
normal operationat 6bar:
approx. 5.1Nl
• Air consumptionof astandard
cylinderDSBC32-500when
advancingat 6bar andwith
pressure reduced to3bar dur-
ing the returnstroke: approx.
4.0Nl
A
ll inall, air consumption is
reducedby22%.
6
2
8
4
bar/psi
Adjust thepressure level to
meet the requirement
If valve terminalswithvertical‑stacking regulatorsareused, the
pressure level canbeeasily
adjusted to theapplication’s
actual requirements. Thismakes,
for example, a returnstrokewith
reducedpressureeasy to imple-
ment.
Inmanyapplications, full force isonly required inonedirection. Pressure canbe cut inhalf for the return
strokewithout causinganyproblems. This isespeciallyeasy toachieve if valve terminalswithvertical-stacking
regulatorsareused. Compressedair consumption canbe reducedbymore than20%.
