Woodworking and wood processing industry

Trimmerzylinder DSBC

Trimmer cylinders: modular system of different wiper seals and cushioning systems

  • ISO VDMA 15552 standard
  • with special wiper seal and special end-position cushioning
  • Developed for tough and difficult conditions, high speeds or loads, difficult environmental influences such as resin and ice

Cylinders for the drying process

  • ISO VDMA 15552 standard
  • Specially for the stringent requirements in the drying process


Source: Michael Weinig AG

Pressure cylinder

It is used to clamp the wood with a defined clamping force via pressure rollers while it is being processed at high speeds.

  • Single-acting special cylinders with reinforced piston rod
  • Designed to absorb major lateral forces
