Pitch slide module
DHMP/DHMB
Standard cylinder
ADN-PPS to ISO 21287
with PPS cushioning
No need to configure it yourself – just
click and go!
The DHMP/B is the first of its kind in the
world. It is perfect for fast picking, spreading
and separation of small parts. Light and
compact, it can be used instead of large and
complex solutions, especially in tight spaces
where short strokes are required. Includes
simple construction and commissioning!
• Min. 10 million cycles without guide
backlash
• Linearity and parallelism approx. 1/100 mm
• DHMB: basic slide version, DHMP:
with additional Z-stroke
• Highly versatile; wide range of
configurations
Choose the benefits you want to use.
High feed force for large, externally guided
loads, or a low-cost option for simple tasks
with light loads: ELGA-TB-G. A simple
principle, more compact with swivelling and
gripping in one. Highly versatile:
position the motor on the left or right on both
axis ends for all servo and stepper motors –
and change it again at any time!
• Speed up to 5 m/s, acceleration
up to 50 m/s
2
• High feed force of up to 1,300 N
• Ready-to-install axis
Reliable and easy configuration of the
ELGA-TB-G with PositioningDrives.
02
Electric toothed belt axis
ELGA-TB-G with
plain-bearing guide
Adjusting the cushioning? Fine tuning?
You can leave all that to PPS.
ADN-PPS: maximum productivity in tight
spaces. The world's first pneumatic end-
position cushioning system PPS
automatically adjusts itself to changes in
load and speed. This saves time and
increases your process reliability, not least
due to the reduced vibrations.
• High cycle times possible
• Ideal for OEMs: no unintentional
re-adjustments
• Up to 50% shorter than the standard
cylinder ISO 15552 – with the same stroke!
Gain 5 minutes for each cylinder mounted –
it pays off.
01
22
New products 2012
