Radial gripper HGRT
Extremely harsh conditions? No problem!
Grippers HGxD are completely sealed,
allowing them to withstand even dusty or
damp environments without any problem and
still grip very precisely. Maximised gripping
reliability is guaranteed, even with high
torques – especially with the optional
opening/closing gripping force backup.
• Total gripping force up to 3,900 N (HGPD)
or 3,000 N (HGDD)
• Force pilot operated with repetition
accuracy from 0.01 mm
• Tubeless compressed air supply with
optional adapter plate
• Highly efficient sensing with protected
proximity sensors
Ideal for:
www.festo.com/automobil
Sealed parallel gripper
HGPD, sealed 3-point
gripper HGDD
Unshakable: reliable and precise
operation.
Keep your grip in every situation. This sturdy
radial gripper is characterised by high torque
resistance, absolute precision and gripping
reliability, even with long gripper jaws.
Sealing air keeps it from getting
contaminated, while the freely adjustable
gripping angle (up to 90° per gripper finger)
ensures optimum cycle times.
• Gripping force backup with compression
springs in case of pressure failure
• Total gripping torque up to 84 Nm at 6 bar
• Precisely polished plain-bearing guides for
reliable gripping
Gripping and inspection in one –
a worthwhile investment.
Scratches or cracks? Once upon a time,
perhaps. But the single-acting DHEB grips
the workpieces safely and gently from the
inside. It also checks during transport
whether the workpiece is leak-proof. For even
greater process reliability, why not choose
optional proximity switches or sensors?
• 11 sizes with gripping diameter
up to 85 mm
• Upward or downward bellows movement
• Bellows materials EPDM for higher loads or
silicone for higher temperatures
Bellows gripper DHEB
For more detailed information, visit our products page:
www.festo.co.uk
