3-point gripper DHDS
Perfect for packing a lot into a small space.
Slim, precise and powerful: the design of the
new standard parallel gripper allows it to be
used as an external or internal gripper.
It really stands out with its high load
bearing, very precise T-slot guide and the
high gripping force of the gripper jaws.
No interfering contours – minimal space
required.
• Single and double-acting
• Gripping force backup and support
• Gripper jaw centring option
• Max opening stroke 25 mm
Reliable and efficient gripper design with
software tools from Festo.
04
Parallel gripper DHPS
Make the standard your benchmark: DHDS!
Its small size and minimal space
requirements provide a stark contrast to its
high gripping force. It includes the high load
bearing T-slot guide for a precise gripping
movement and the sturdy lever actuator for a
long service life and a high level of process
reliability. Suitable for inside and outside
gripping.
• Max. gripping diameter 50 mm
• Gripping force of up to 840 N
• Single and double-acting
• Gripping force backup and support
Everything you need to know about
DHxS.
05
More grip on the production line!
Slim, powerful and with great repetition
accuracy, just like its cousins. Suitable for
situations where space is limited. And
another plus point: the DHRS has a lateral
gripper jaw support for high torques, while
the link guided DHWS has optimised gripper
jaw bearings with synchronised jaw
movement.
• Single and double-acting
• Gripping force backup and support
• Self-centring gripper jaws with
additional centring option
• Total opening angle DHRS 180°,
DHWS 40°
A wide variety of grippers for every task.
06
Radial gripper DHRS,
angle gripper DHWS
24
New products 2012
