Valve terminals
MPA-S/MPA-F/MPA-L
Valve expansions
No control cabinet required: make ATEX
easy – and up to 70% cheaper.
With convenient and easy installation,
the CAFC-X1-GAL enables you to meet the
special requirements for using CPX/MPA in
ATEX zones with the minimum of fuss. Also
available on request as a complete solution
from Festo, e.g. as a pre-assembled
installation plate.
• 50% – 70% cheaper than a control cabinet
• Up to ATEX Zone 2/22, close to the process
• Space saving; no construction work
required
• Alternative to the "pneumatic multiple
connector plate"
• Intended for use as an additional safety
mechanism
More information on ATEX.
09
Hood CAFC-X1-GAL
for CPX
Consistently expanded – so MPA can do
even more for you.
New: larger proportional-pressure regulator
VPPM-MPA
1
/
4
" for precise control of
pressure, force, pressure zones or individual
pressure.
New: directional control valves for low
pressure between –1 and 3 bar, e.g. for
holding, pressing in or use in safety
engineering.
New: MPA-L – super-modular. Lighter
materials and angled cartridges
save weight, space and costs.
• VPPM-MPA in nominal diameter 8 for 380 …
1,650 l/min and on the spot diagnostics
• 2x2/2-way, 2x3/2-way and 5/2-way valves
with combined mechanical spring reset and
pneumatic spring
• MPA-L: all sub-bases connected individually
for greater flexibility, modular in single
steps
The full picture – possible areas of
application for VPPM-MPA.
10
You can now use the compact and modular
MPA-ASI in accordance with spec. 3.0 in A/B
operation.
Twice as many I/Os as a master! Spec. 3.0.
allows address ranges 1A – 31A and 1B – 31B
for installation of binary sensors or actuators.
This reduces the channel price by up to 50%!
Includes all the benefits of the MPA with
pressure zones, vertical stacking and
diagnostics.
• Design Spec. 3.0 , profile 7.F.E. with
4I4O/8I8O in the MPA-ASI module 546279
• Required ASI master M3
• 4/8/16 I, 4/8/16 O; bus times 20 ms,
496 I/O or 248 I/248 O
• Wide range of accessories, e.g. cable socket
NEFU-X2. Adapted AS interface flat cable
with M12 plug
Top products for the ASI master CESA from
Festo, top support for the ASI world: so that
you can build complete systems.
11
Valve terminal MPA-ASI
extension
