Remote I/OTerminal –CPX-P (Namur)
• NAMUR compatible inputmodule
• Explosionproof for cabinetsup toZone2
• Partitionsbetweenmodules toprocess intrinsicallysafeandnon-intrinsicallysafesignals
InstallationSystem–CPI
• Complete concept for decentralizedsystemstructure
• Four CPstringsup to10m in length (radius) facilitateoptimumdecentralization
• Maximumof 32 inputsand32outputsvalvesper string
• Displayof the input statusof each input signal viaanassignedLED
No. of output
Protection class
Power supply
[24VDC]
Operatingvoltage
[mA]
Operatingvoltage for
sensors
16...32
IP65
CPconnection
Typically75
24
PneumaticValveTerminals
ValveTerminal –MPA/MPA-F/MPA-L
• Slimhighperformancevalve insturdymetal housing
• Withmulti-pinplug, AS-interface, CPI, andfieldbus connectionviaCPX terminal
• Expandable toup to128solenoid coils
• TheLEDson thevalvesanddiagnosticsviafieldbusallows fast troubleshooting
• Hot Swapmodule– individual valve couldbe replacedwithout shuttingdown thewholemanifold
Ambient temperature
[°F]
Flow rate
[l/min]
Valvewidth
[mm]
Operatingvoltage
[V]
Operatingpressure
[psi]
23...122
up to700
10...21
24DC
-13...145
CompactValveTerminal –VTUG
• Spaceoptimized for cabinet installation
• Bulkheadmount to cabinetwall
• Multi-pinor fieldbus connectivity
• Expandable to24solenoids coils
Valvewidth
[mm]
Flow rate
[l/min]
Ambient temperature
[°F]
Operatingvoltage
[V]
Operatingpressure
[psi]
10mm...14mm
130...630
23...140
24V
-13...116
ISOCompliantValveTerminal –VTSA/VTSA-F
• Highperformancevalves insturdymetal housing
• Standardized frommulti-pinplug to thefieldbus connectionand control block
• Expandable toup to32solenoid coils
• Fast troubleshooting: LEDson thevalvesanddiagnosticsviafieldbus
• Vertical shut-offmodule– individual valve couldbe replacedwithout shuttingdown thewholemanifold
• Available inNPT thread
Duty cycle
[%]
Flow rate
[l/min]
Valvewidth
[mm]
Operatingvoltage
[V]
Operatingpressure
[psi]
100
400...2,900
18...52
24DC; 110AC
-13...145
SanitaryValveTerminal –CDVI
• Sanitarydesign forwashdown, corrosion resistant, and cleanapplications
• FDA compliant lubricants - FDANSF-H1
• Expandableup to24valves
• Fieldbus connectionsviaCTEU
Duty cycle
[%]
Flow rate
[l/min]
Valvewidth
[mm]
Valveposition
Operatingpressure
[psi]
100
300...650
24
4...16
-13...145
NetworkandElectrical I/O terminals
Modular Electrical Terminal –CPX
• Fieldbusnodewith integratedanaloganddigital I/O, I/P, andpneumaticvalves
• Suppling leadingprotocols: EtherNet/IP, DeviceNet, PROFIBUS, PROFINET, PROFIsafe, ASi, EtherCAT,ModbusTCP,
CC-Link, INTERBUS, CANopen
• Direct integrationwithMPAorVTSAvalve terminals
• Availablewith integratedCoDeSys controller (IEC61131)
• Detailedpoint diagnostics for electronicsandpneumaticsviaLED, local hand-held, laptop, or communicated toPLC
• I/O connections: Terminal strip,M8,M12,Harax
I/Omodules
CP interface
Multi axis interface
Max. inputs capacity
[byte]
Max. outputs capacity
[byte]
Operatingvoltage
[V]
Protection class
Up to9
64
64
24DC
IP65/IP67/IP20
