Industrial ProcessValveAssemblies
2pcBallValveActuatorAssembly–VAPB-2F
• Full port stainlesssteel 2pcball valve
• Complete testedassemblywitheither doubleor singleacting¼-turnactuator
• ISO/NAMUR/VDI/VDE interface for accessories
• Suitable forwide rangeof fluidsand inert gases
Valveseal
Connectionsize
[NPT]
Temperature range
[°F]
Actuator supplyair
pressure [psi]
Mediapressure
[psi]
RTFE [15%G.F.] and
PTFE
1/4"…3"
-20...420
min. 80DAor
min. 72.5SA
1/4"...2"1000
2-1/2" - 3"800
3pcBallValveActuatorAssembly–VAPB-3F
• Full port stainlesssteel 3pcball valve
• Complete testedassemblywitheither doubleor singleacting¼-turnactuator
• ISO/NAMUR/VDI/VDE interface for accessories
• Suitable forwide rangeof fluidsand inert gases
Valveseal
Connectionsize
[NPT]
Temperature range
[°F]
Actuator supplyair
pressure [psi]
Mediapressure
[psi]
RTFE [15%G.F.], 50%
316SSfilledPTFE&
HMWPE
1/4"…4"
-20...420
min. 80DAor
min. 72.5SA
1/4"...2"1000
2-1/2"...4"800
3-wayLandTPortBallValveActuatorAssembly–VZBA-4F-LorT
• Full port stainlesssteel 3-wayball valve
• Complete testedassemblywitheither doubleor singleacting¼-turnactuator
• ISO/NAMUR/VDI/VDE interface for accessories
• Suitable forwide rangeof fluidsand inert gases
• Balanced4-seat construction
Valveseal
Connectionsize
[NPT]
Temperature range
[°F]
Actuator supplyair
pressure [psi]
Mediapressure
[psi]
RTFE [15%G.F.]
1/4"…2"
-20...420
min. 80DAor
min. 72.5SA
1/4"...1"1000
1-1/4"...2"800
WaferButterflyValveActuatorAssembly–VZSA-W
• Centricdesign
• Complete testedassemblywitheither doubleor singleacting¼-turnactuator
• ISO/NAMUR/VDI/VDE interface for accessories
• Bi-directional bubble-tight shut off
• Face-to-facemeets ISO5752 table5short
Valveseal
Connectionsize
[NPT]
Temperature range
[°F]
Actuator supplyair
pressure [psi]
Mediapressure
[psi]
NBR, EPDMstandard
[optionsavailable]
1-1/2"…24"
[ANSI 125/150]
-4...248
(dependingonseat
material)
min. 80DAor
min. 72.5SA
1-1/2"...12"230
14"...24"150
LugButterflyValveActuatorAssembly–VZSA-L
• Centricdesign
• Complete testedassemblywitheither doubleor singleacting¼-turnactuator
• ISO/NAMUR/VDI/VDE interface for accessories
• Bi-directional bubble-tight shut off
• Face-to-facemeets ISO5752 table5short
Valveseal
Connectionsize
[NPT]
Temperature range
[°F]
Actuator supplyair
pressure [psi]
Mediapressure
[psi]
NBR, EPDMstandard
(optionsavailable)
1-1/2"…24"
[ANSI 125/150]
-4...248
(dependingonseat
material)
min. 80DAor
min. 72.5SA
1-1/2"...12"230
14"...24"150
ButterflyValveActuatorAssemblyAWWA–VZSA-A
• ConstructedperAWWAC-504-00
• Complete testedassemblywitheither doubleor singleacting¼-turnactuator
• ISO/NAMUR/VDI/VDE interface for accessories
• Bi-directional bubble-tight shut off
• Face-to-face lay lengthperAWWAC-504-00 class150B, table1
Valveseal
Connectionsize
[NPT]
Temperature range
[°F]
Actuator supplyair
pressure [psi]
Mediapressure
[psi]
NBR, EPDM
(vulcanized resilient
seat)
3"…24"perAWWA
C-504-00 table2,
ANSI B16.1 class125
-4...248
(dependingonseat
material)
min. 80DAor
min. 72.5SA
3"...24"150
