SanitaryProcessValvesAssemblies
SanitaryBallValveAssemblywithActuator –VAPS-7F
• True tube full port sanitarystainlesssteel 3pcball valve
• Complete testedassemblywitheither doubleor singleacting¼-turnactuator
• ISO/NAMUR/VDI/VDE interface for accessories
• Suitable forwide rangeof fluidsand inert gases
• Corrosion-resistant 316LSS (A351GR.CF3m), 20Ra internal surfacefinish
Valveseal
Nominal diameters
Temperature range
[°F]
Actuator supplyair
pressure [psi]
Mediapressure
[psi]
RTFE [15%G.F.], PTFE,
TFM cavityfilled, PTFE
cavityfilled
1”...4”
DN25....DN100
-20...420
EPDN: -0.4...+248
FPM: +5...+356
to145
FoodGradeBallValve -VZBB
• Suitable for sanitary liquidapplications includinghighviscosityand containingsolidparticles.
• Corrosion-resistant 316L forgedbody, 20Ra internal surfacefinish (304Lavailable)
• Simple interface topneumaticactuators
• Materials compliant to FDA177.2600
• Traceabilityof components
Valveseal
Nominal diameters
Connection types
Temperature range
[°F]
Mediapressure
[psi]
EPDM
FPM
1”...4”
DN25....DN100
Weld,male,
clamp, nut
EPDN: -0.4...+248
FPM: +5...+356
to145
FoodGradeButterflyValve–VZFA
• Suitable for liquidproduct application inpharmaceutical, foodprocessing, and chemical industries
• Corrosion-resistant 316L forgedbody, <0.8Ra internal surfacefinish (304Lavailable)
• Simple interface topneumaticactuators
• Materials compliant to FDA177.2600
• Traceabilityof components
Valveseal
Nominal diameters
Connection types
Temperature range
[°F]
Mediapressure
[psi]
EPDM (standard)
FPM
NBR
1”...4”
DN25....DN100
Weld,male,
clamp, nut
EPDN: +14...+268
to145
QuarterTurn Actuator StainlessSteel –DAPSCR
• Full stainlessbodyandshaft (1.4408/316C16Cast)
• Flangeholepatterns to ISO5211
• Scotch-yokemechanism, twinpistonbalancedpinion force
• Interfacesaccording toVDI/VDE3845andNAMUR for accessorymounting
• Availablevariant: Epoxy coating, PTFE coatingand low temperature (-122°F)
Function
Ambient temperature
[°F]
Pressure range
[psi]
Torqueat 73-87psi
[Lb
•
In]
Swivel angle
[°]
Double-acting
-4...176
36.5...121.8
133...4,248
0...90
Single-acting
-4...176
36.5...121.8
133...2,124
0...90
StainlessSteel Linear-RotaryActuator for Food Industry
• Full stainlessactuator for sanitaryapplications
• HousingAISI 304L,HeadAISI 316L
• Suitable forwashdownenvironment
• Pneumaticpilot operated linear actuatorwhich is converted to linearmotion
• Preconfiguratedandpreassembled from FestowithVZBBball valveorVZFAbutterflyvalve
Control Head for Food Industry - CPPI
• Provides local control of sanitaryprocessvalves
• ASi or digital communication
• Sanitarydesignsuitable forwashdownenvironment
• LargeLED for easyvisual indication
• Preconfiguratedandpreassembled from FestowithVZBBball valveorVZFAbutterflyvalve
