Pneumatics and Hydraulics Learning Solutions for Technical Education and Training
Table of contents Magazine Turnkey Educational Solutions M6 Complete Solutions from Planning to Installation M8 Flexible Room Concepts M10 Innovative Technologies in Modern Workplace Systems M12 Customer Reference Daimler Training Center in Stuttgart, Germany M14 Training Packages M16 The Educational Concept of the Complete Action M18 Pneumatics and Hydraulics Training Packages M20 The Digitalization Learning Path and Networking M22 Energy Management and Predictive Maintenance M24 Customer Reference Phenikaa University in Hanoi, Vietnam M26 Digital Learning M28 Digital Learning Combines Theory and Practice M30 Customer Reference Freudenberg in Weinheim, Germany M32 WorldSkills M34 Festo Promotes Professional Competitions M36 Service M38 Reliable and at Our Customers' Side M40 M2 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training
Workstation Systems 2 The Didactic Concept 22 Pneumatic Overview and Structure 24 System Description 26 Pneumatics Learning Path towards Digitalization 28 Pneumatics Training Packages 30 Hydraulics Overview and Structure 25 System Description 74 Hydraulics Training Packages 76 Components 114 Digital Learning 162 Table of contents Products M3 → www.festo.com
Magazine
Turnkey Educational Solutions Tailored to Customer Requirements M6 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Turnkey Educational Solutions
01 „Turnkey educational solutions are an investment in the future. They provide all the required resources and teaching materials from a single source. “ Dr. Nader Imani, Head of Global Education Overlay M7 → www.festo.com Magazine > Turnkey Educational Solutions
Concepts for Every Challenge Complete Solutions from Planning to Installation Customized solutions from a single source Every educational institution has different requirements in terms of budget, space, performance level, and technology orientation. Although their needs differ, they all have one goal in common: to ensure that young people in education or employees on the labor market get the best possible qualifications. Is it your task to get the most out of a small space, or to make sure that new laboratories are optimally planned? Does everything revolve around hardware, software, or training in fluid technology? Or are you concerned about the topic of digitalization and simulation as a way of transferring knowledge of basic technologies? Festo Didactic has been providing answers to customers' questions all over the world for over 50 years, and develops a customized complete solution for every challenge. This offers educational and training facilities a consistent and future-proof concept from a single source. And students will be able to get exactly the technical qualifications that are currently in demand on the job market. Scan me M8 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Turnkey Educational Solutions > Concepts for Every Challenge
Metal Technology Mechatronics/ Factory Automation Electrical Engineering/ Electronics/ Drive Technology Process automation Process Automation Environmental Technology Fluid Engineering Industry 4.0 Building System Technology → www.festo.com M9 Magazine > Turnkey Educational Solutions > Concepts for Every Challenge
For Different Age Groups and Technologies Flexible Room Concepts Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Turnkey Educational Solutions > For Different Age Groups and Technologies M10
One space – a wide range of technologies Ideally, you would be teaching apprentices from different age groups and different disciplines in the same space. However, how spaces can be used is often limited by inflexible furniture. Our flexible room concepts offer the opportunity for training across different technologies. They consist of complete laboratory workstations with mobile furniture, workbenches, and machines. Depending on the lesson, students can work in project groups or focus on self-study phases. Even when setting up, we are already thinking about expansion options in the future. The ingenious TecDesign system offers the greatest possible flexibility for practical teaching. Flexible swivel arms with integrated connections supply the room with compressed air, energy, and data in the shortest possible time. The space is thus used in different ways and to optimum effect as well as to full capacity. This benefits teachers and students alike. →Discover laboratory variants in the “Room concepts” brochure Scan me → www.festo.com M11 Magazine > Turnkey Educational Solutions > For Different Age Groups and Technologies
Optimal Learning with Flexible Furniture Innovative Technologies in Modern Workplace Systems Learnline Theory is followed by practical application. The workstation systems in the Learnline series provide an ideal training environment for education and training in automation technology. The modular combination of furniture and components leaves nothing to be desired, for training on basic technology all the way to digitalization. Innovative technologies in pneumatics and hydraulics are easy to teach at these stations. Each station is individually equipped for a specific application area. The advantage is particularly important for smaller educational institutes, as a single laboratory with different stations can be used flexibly for training different professions. The mobile furniture is very practical and enables optimum use of the space. A decisive advantage of the training packages are the genuine industrial components from Festo. This gives students the opportunity to get close as possible to industrial production. Future employers know that these people have mastered the necessary skills when they start their new job and are immediately ready for action. M12 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Turnkey Educational Solutions > Optimum Learning with Flexible Furniture
B Frameline With this highly flexible solution for electrical engineering, the laboratory is already equipped for tomorrow. The equipment can be expanded modularly and quickly adapted to individual requirements. Traditional frontal teaching has had its day. Learning means discovering, trying things out, and having fun. The best way to achieve this is through variety: discussions, creative learning, and sharing ideas are important. The Frameline furniture series is particularly suitable for teaching people individually, in pairs, or larger groups. It takes just a few moments for teachers to rearrange the mobile modules as required. Are ergonomic seating, an orderly room, and multi-media all part of training for you? All these different elements are of course an integral part of the program in the fully equipped workstation systems. Because we want teachers to concentrate fully on what they do best: giving exciting lessons. →Our brochure “Furnishing individual learning spaces” shows you all the options Scan me M13 → www.festo.com Magazine > Turnkey Educational Solutions > Optimum Learning with Flexible Furniture
Training in The Automotive Industry Customer Case Study: Daimler Training Center in Stuttgart, Germany M14 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Turnkey Training Solutions > Training in the Automotive Industry
One room – many possibilities Learning spaces and laboratories are often unchangeable. So how do you get the most out of small spaces and how can you teach different disciplines in the same room? Festo Didactic offers individual and creative solutions for every room. A good example is the Daimler Training Center in Stuttgart, Germany. Two learning rooms were equipped with multifunctional equipment. This includes the flexible TecDesign system, as well as mobile furniture and learning stations. It is now possible to teach students from different year groups and different disciplines on the same day. Many areas are covered at the Daimler Training Center: pneumatics and electropneumatics, mechatronics, factory automation, and the basics of Industry 4.0. Even non-technical lessons such as presentations or group work are now easy to organize. The customer benefits are obvious: minimize vacancies, improve capacity utilization, and simplify lesson planning. →You can find more details about the learning space here Scan me M15 → www.festo.com Magazine > Turnkey Training Solutions > Training in the Automotive Industry
Training Packages Get to Know the Function and Features of Technologies M16 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training 16 Magazine > Training Packages
02 „Training packages are the ideal combination of hardware, software, didactically prepared learning content, and practical exercises. “ Nicola Bauer, Head of Factory Automation M17 → www.festo.com Magazine > Training Packages
Developing and Implementing Skills The Educational Concept for Full Competence Applying key competencies Employees with the right skills are a success factor, because people are also at the heart of the industrial transformation. Intelligent machines need employees who are well trained and have the skills to take on responsibility. The concept of the complete action helps them to do this as they follow a cycle of five steps. They can identify their own position in the process at any time. Going through the entire process is one of the requirements of the economy for skilled workers. It guarantees the quality of work processes. In our training packages and learning systems, students apply both the skills they have acquired and the concept in practice. Magazine > Training Packages > Developing and Implementing Skills The educational concept for total performance. Our educational concept for the training modules. Informing Reflecting Documenting Planning Checking Implementing Total performance M18 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training
Informing • Reading the problem description in the workbook • Understanding the assignment • Acquiring any missing knowledge Planning • Designing a circuit with FluidSIM® • Generating a circuit diagram with a bill of materials Implementing • Designing and commissioning the circuit on a workstation system using the training packages • Simplified, accessible, and convenient Evaluating • Comparing the target and actual state and specific troubleshooting, e.g., using measuring technology components Reflecting, documenting • Evaluating the result, optimization and professional documentation using the worksheets in the workbook and FluidSIM CAD drawings Magazine > Training Packages > Developing and Implementing Skills The concept using the example of simulation software M19 → www.festo.com
Comprehensive Basic Knowledge of Fluid Technology Pneumatics and Hydraulics Training Packages Pneumatics training packages Pneumatics is a core element of drive technology in industrial production systems. As an automation specialist, Festo offers training packages in pneumatics for almost every application and for every level. The training packages are specially tailored to their application. Matching hardware, software, and workbooks are combined to create a comprehensive learning experience. The modular packages, covering topics from basics to specialization, build on each other, creating a logical learning paths for getting to grips with the technical basics. And why not take a different approach? Learn or teach wherever you want. The mobile training packages TP 101 and 201 make for exciting new learning environments and ensure your training rooms will be fully occupied. →You can find our learning solutions on pneumatics on page 28 Hydraulics as energy-efficient drive technology Compared to other drive technologies, it is capable of transmitting high forces and torques without consuming large amounts of energy. As in all technologies, digitalization is also becoming increasingly important in hydraulics. Our training packages make it easy to learn how to monitor and analyze data. The next logical step is predictive maintenance, which helps to avoid downtime. Energy efficiency and preventing production disruptions protect our environmental resources. This is how technical education can make a contribution to sustainability. →You can find our learning solutions on the Digital Factory on page 162 M20 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Training Packages > Comprehensive Basic Knowledge in Fluid Technology
M21 → www.festo.com Magazine > Training Packages > Comprehensive Basic Knowledge in Fluid Technology
The Indispensable Control Systems and Data Management The Learning Path for Digitalization and Networking The learning path for digitalization The case study of the German metalworking profession makes it clear that the learning path for digitalization prepares students for the challenges of digitalization. They build up important skills, e.g., an understanding of digitally networked production processes or the programming of programmable logic controllers (PLCs). The learning path helps metalworkers to adapt to the requirements of an increasingly digitalized working world. In addition to technical skills, the young specialists are also trained in teamwork, communication, problem solving, and analytical thinking. →You can find our learning solutions on the topic of the Digital Factory on page 162 M22 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Training Packages > Controls and Data Management
Connected world By networking PLC systems, production processes can be efficiently and intelligently controlled and monitored. Operating data is recorded, visualized, and controlled, enabling production to be optimized. Networking also allows machines and systems to be monitored and controlled remotely. When trends, patterns, and optimization potential are identified, production processes can be continuously optimized and efficiency will increase. The networking, operation and monitoring of PLCs thus contributes to intelligent networked production, which in turn leads to greater flexibility, efficiency, and quality. →You can find our learning solutions on the topic of the Digital Factory on page 162 M23 → www.festo.com Magazine > Training Packages > Controls and Data Management
Conserve Resources and Avoid Downtime Energy Management... Sustainability in production Energy management means that the energy consumption in systems and processes are efficiently monitored, controlled, and optimized. In predictive maintenance, data analysis helps to monitor the condition of machines and predict upcoming maintenance requirements. Specialists in industry today need new skills. This includes dealing with energy sources, measuring and monitoring systems, as well as data analysis, sensor technology, and machine learning. This knowledge will help them avoid unplanned downtime, extend the service life of the equipment, and reduce costs too. Optimizing operating processes and making systems more reliable is easier than you might think. Our learning solutions for energy management or sensor technology guide you step by step towards the skills that are in high demand in modern and sustainable industry. →You can find our learning solution AirCS on energy management on page 70 Energy savings Energy efficiency in compressed air M24 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Training Packages > Conserving Resources and Avoiding Downtime
... and Predictive Maintenance Minimizing risks and optimizing processes In our globalized world, no company can afford an idle production line. It is therefore all the more important to have highly trained employees who know how to monitor the condition of the equipment, thus preventing potential breakdowns. Training institutes are called upon to equip young professionals with the right skills. Condition monitoring focuses on the continuous monitoring of system processes. This allows deviations from normal operating parameters to be detected in good time. The advantages are longer system availability, risk minimization, and improved maintenance. As an automation specialist, Festo knows the needs of industrial companies. Festo Didactic uses this up-to-date industry know-how to develop modern learning solutions for educational institutes. Take a look at the Intelligent Sensors training package and how it can be flexibly integrated into your lessons. →You can find our learning solution on the subject of predictive maintenance at 62 and 94 Scan me M25 → www.festo.com Magazine > Training Packages > Conserving Resources and Avoiding Downtime
Customers Rely on Quality and Training Customer Case Study: Phenikaa University in Hanoi, Vietnam M26 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Training Packages > Customers Rely on Quality and Training
Modern teaching of basic technology The private Phenikaa University is located in Hanoi in the north of Vietnam. It teaches the subjects of technology, economics, medicine, biology, and materials. The managers were looking for a high-quality learning solution for the basics of pneumatics that would also cover digitalization. This is where future mechanical and mechatronics engineers are trained. They first learn the theory and then put it into practice using industrial components. Interfaces are configured on the computer with the relevant software. Between 14 and 20 students can study in one room at the same time. The decision of Phenikaa University to choose Festo was based on several reasons: its partner Festo has a local office in Hanoi, the high-quality equipment comes from a single source, and is cost-efficient to use. The train-the-trainer program for teachers also impressed the customer. Other learning rooms have been equipped with MPS 403-1, PLCs, and sensors. M27 → www.festo.com Magazine > Training Packages > Customers Rely on Quality and Training
Digital Learning Digital Learning Support for Efficient Learning Processes M28 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Digital Learning
03 „ Digital learning focuses on the student and adapts to individual knowledge and needs. “ Dr. Ute Gebhard, Head of Digital Learning M29 → www.festo.com Magazine > Digital Learning
A New Form of Teaching Digital Learning Combines Theory and Practice The digital transformation is shaping and permanently changing the world of education. In technical education, in particular, it is important to impart more than just theoretical knowledge. Students must also be given the opportunity to apply and deepen the skills they have acquired directly in practice. This is precisely the objective of the digital learning solutions from Festo Didactic. The combination of theory and practice is easy to implement with the Festo LX Digital Learning portal. It offers plenty of training content on the basic technologies of pneumatics and hydraulics. →You can find our learning solutions for Festo LX on page 164 With our comprehensive FluidSIM software solution, virtual simulations and models of pneumatic, hydraulic, and electrical circuits can be designed. →You can find our learning solutions for FluidSIM on page 168 M30 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Digital Learning > A New Form of Teaching
M31 → www.festo.com Magazine > Digital Learning > A New Form of Teaching
Tomorrow's Specialists Learn Digitally Customer Case Study: Freudenberg in Weinheim, Germany M32 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Digital Learning > Tomorrow's Specialists Learn Digitally
The Freudenberg company in Weinheim, Baden-Württemberg, Germany, is a global and innovative provider of technology. As a training company, Freudenberg attaches great importance to state-of-the-art digital training for its students. The young specialists use Festo LX to learn complex topics in short units, ensuring that the link between theoretical knowledge and practical application focuses on professional performance. Festo LX is used in close combination with pneumatic and hydraulic components and with elements of metalworking equipment, such as lathes and milling machines. “Festo LX offers a range of courses that are optimally linked to the Festo hardware. It provides user-friendly layouts for creating your own content, which helps to find simple ways to communicate complex topics,” explains Martin Bechtold, Technical Trainer for Digitalization at Freudenberg. Scan me M33 → www.festo.com Magazine > Digital Learning > Tomorrow's Specialists Learn Digitally
WorldSkills We Create Winners M34 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > WordSkills
04 „ Vocational competitions in Germany and abroad bring together decision-makers from education, business, and government. Together, they are shaping the professions of the next generation. “Elfi Klumpp, Head of Partnership Development Global Education M35 → www.festo.com Magazine > WordSkills
Inspiring Young People for Technical Professions Festo Promotes Professional Competitions Strong partnership The WorldSkills Association has been organizing national and international vocational competitions since 1950. Thousands of young professionals around the world demonstrate their skills in over 60 training occupations year after year. Festo and WorldSkills International have enjoyed a close partnership since 1991. As a Global Industry Partner (GIP), Festo introduces the latest technology trends from the industry to the vocational competitions. Today, we sponsor the subjects Mechatronics, Industry 4.0, Water Technology and Renewable Energy. Since 2008, WorldSkills Europe and Festo have been working together to promote training in technical professions. In recognition of this cooperation, Festo received the Premium Sponsor award from WorldSkills Europe in 2022. Well-trained specialists are increasingly in demand. At Festo, we actively support the training of skilled workers by promoting vocational training, making it better known and ensuring it gets better appreciated. International championships act as a magnet for participants and visitors alike and inspire young people to take up technical professions. In order to bring about technological change, they need to put in a top performance. →You can find our commitment to WorldSkills on our website M36 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > WorldSkills > Inspiring Young People for Technical Professions
Those who learn are always on the winning side Festo Didactic develops the official equipment for the sponsored subjects and updates it every year. The young participants perform extremely well in their professions using the state-of-the-art learning systems. Fluid technology plays an important role in the 04 Mechatronics discipline, but also in the 01 Industrial Mechanics, and 19 Plant Electrical Systems disciplines. Industry-related pneumatic components are installed in a small format automated production systems. The young participants use the FluidSIM simulation software to design virtual electrical systems. The practical training packages from Festo Didactic provide apprentices with the best possible preparation, whether for professional competitions or for their first job. →You can find our learning solutions on fluid technology from page 23 onwards →You can find our learning solutions for FluidSIM on page 168 Scan me M37 → www.festo.com Magazine > WorldSkills > Inspiring Young People for Technical Professions
Service Always There for The Customer M38 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Service
05 Markus Bellenberg, Global Technical Customer Service „ Our customers can expect efficient and individual solutions from us at all times. This includes fast response times and transparent communication. “ M39 → www.festo.com Magazine > Service
Good Partnership Knows No Boundaries Reliable and at Our Customers' Side Close to the customer Of course Festo is there for customers even after the purchase has been completed. Commissioning, training, or train-the-trainer sessions can take place anywhere in the world on request. Customers in industry and educational institutes both benefit from this after-sales service, enabling them to make optimum use of their learning solutions. Festo is always close to the customer. It provides support for customers in more than 60 companies. The subtle difference lies in the service – for us, the customer is a longterm partner. They can rely on our many years of international experience in the global market and expect a suitable solution for your individual challenge. And, needless to say, in their national language and with short response times. →You can find our learning solutions on the topic of service on page 174 M40 Pneumatics and Hydraulics I Learning Systems and Services for Education and Training Magazine > Service > Good Partnership Knows No Boundaries
Service is a top priority Every customer is individual, and so too is their communication behavior. Festo is fully committed to its customers. You can reach us simply by phone or email. Already at this point, we differentiate between technology and software topics to ensure you get a quick answer. Our ticket system offers the greatest possible transparency in communication and solution finding. The Didactic InfoPortal provides documentation and specialist product information around the clock. If you want to stay up to date, subscribe to our newsletter. For problem solving in real time directly on your system, you can communicate with the experts at Festo via the TeamViewer Quick Support software program. Possible returns can be processed quickly by telephone or by completing a downloadable form. Whatever your request, Festo is always there for you. Scan me M41 → www.festo.com Magazine > Service > Good Partnership Knows No Boundaries
Products
1 Workstation Systems.........................................................................................2 The Training Concept.......................................................................................22 Pneumatics and Hydraulics Training Packages.................................................23 Pneumatics Training Packages Overview and Structure...................................................................................24 System Description..........................................................................................26 Pneumatics Learning Path Towards Digitalization............................................28 Pneumatics Training Packages.........................................................................30 Hydraulics Training Packages Overview and Structure...................................................................................25 System Description..........................................................................................74 Hydraulics Training Packages...........................................................................76 Pneumatic Components................................................................................ 114 Hydraulic Components.................................................................................. 134 Digital Learning............................................................................................ 162 Content
2 Workstation Systems
3 Universal Laboratory Furniture. ........................................................................4 Learnline............................................................................................................4 Mobile Learnline................................................................................................6 Stationary Learnline...........................................................................................8 Learnline – Your Individual Design...................................................................10 Learntop-A/Learntop-L. ...................................................................................14 Learntop-S.......................................................................................................16 Frameline®.......................................................................................................18
4 24-month Festo Didactic warranty Workstation Systems > Universal Laboratory Furniture Universal Laboratory Furniture Learnline The modular workstation systems for education and training, offering many practical details that make teaching and learning easier. With Learnline, you are choosing a consistent organizing principle that can be used for teaching either pneumatic, hydraulic, or electrical engineering and that does not need to be converted. Form and function are perfectly combined, and this is visible in every practical detail. Learnline consists of basic mobile and stationary units with cable/ oil trays, various add-on structures and extensions, wheeled and fixed drawer units together with special organizing systems, attachments, and accessories. The modular Learnline workstation system offers a wide range of configurations and add-on options. Expert consultants in over 50 countries can prepare an individual offer for you. Quality from Festo We make no compromises when it comes to quality: workmanship and functionality are of the highest standard. The rigid design and the highquality coating of the work surface and frame guarantee a long service life despite many loads and strains. Learnline can cope with the rigors of everyday teaching, as well as a moving load during hydraulic position control. Learnline easily absorbs high mechanical forces, e.g., from control hydraulics, proportional pneumatics, or robotics add-on top sections. Versatile, flexible, and expandable A look at the basic structure proves that Learnline solves a wide range of requirements. Thanks to just a few individual components that have been thought through down to the last detail, results can be achieved that are geared towards people's needs, the available space, and the technical challenges. The functional profile column is a prerequisite for modularity. It is a central attachment point and as such it opens up a wide range of options for putting together the required configuration. All parts are simply and securely fastened to the profile plate using a T-head nut or the patented Quick-Fix quick fastening system without the need for additional tools. One fastening system for all technologies and applications.
5 → www.festo.com/didactic Benchmark for design and function Learnline – Winner of international design awards: – iF Product Design Award – Focus design award in silver Workstation Systems > Universal laboratory furniture Learnline online configurator Get to know the functional design of Learnline and configure workstations on the Internet according to individual requirements. Do you want a predefined sample workstation or your own configuration? Profile plates, drawer units, and accessories are simply selected and added to your configuration. The result is a graphic representation of the selection with a parts list. Organizers Regardless of whether the training packages are stored in a Systainer or in a drawer unit, the organizers from Festo Didactic always provide a quick overview. The lockable drawer unit has a full extension runner and pull-out stop. Each drawer can carry up to 20 kg. The shipping packaging of the pneumatic and hydraulic equipment sets can be used as a clear drawer insert. This saves material and provides a quick overview of the drawer contents. Integrated electrics The workstations can be used universally with various electrical insert plates, supply channels, and different add-on top sections. The mounting frames are suitable for a large number of exercise boards and ER units. The ER mounting frame is compatible with the electrical components of the training packages. Alternatively, the A4 mounting frame is available, in accordance with the electrotechnical standard.
6 24-month Festo Didactic warranty Mobile Learnline More Versatile Than Ever Before! Flexible and modular Learnline has a modular structure and offers almost unlimited possibilities for configuring the Learnline workstation system. High degree of mobility and optimum utilization of space Areas for individual and group exercise are created where they are needed without any great effort. It can even be maneuvered through doors without any problem. This mobile workstation is designed so that several people can work on it at the same time. This is also made possible by the two integrated fixed drawer units, which provide quick access to the required components of the learning system Workstation Systems > Universal Laboratory Furniture > Learnline Learnline Winner of international design awards
7 → www.festo.com/didactic 1 2 Perfect use of space The storage shelf makes great use of the free space next to the fixed drawer units for Systainers or other organizers. The hydraulic power unit with individual pump is conveniently located next to the 1100 mm wide profile plate. Hydraulics for advanced students The double pump unit fits perfectly next to the fixed drawer units directly on the base frame, without needing any fastening. In addition to the 1100 mm wide profile plate, there is also space for the discharge measuring receptacle. Training in pneumatics and electrical engineering Up to two compressors fit on the storage plate. In addition to the 700 mm profile plate, additional mounting frames can be used for electrical components, e.g., in A4 format. Vertical or angled? The vertical profile plate is useful when using the table surface for workbooks or laptops, for example. Alternatively, you can opt to have an additional profile plate, placed in an inclined position so the station can be used on both sides, with the incline adjustable to suit your needs. 1 With 1100 x 700 mm profile plate and ER frame 539028 2 With 700 x 700 mm profile plate and ER frame 539030 3 With 2x 700 x 700 mm profile plate and ER frame 572155 The attractively priced preferred variants. Flexible extension options. (External dimensions (W x D x H): 1566 x 780 x 1773 mm) 3 Workstation Systems > Universal Laboratory Furniture > Learnline
8 24-month Festo Didactic warranty Workstation Systems > Universal Laboratory Furniture > Learnline Learnline Winner of international design awards Stationary Learnline Ergonomic and Flexible The stationary solution The stationary workstation systems of Learnline meet the requirements for typical desk systems while ensuring high functionality at the same time. They provide extensive table space and ample leg room thanks to the wheeled drawer units. The drawer units ensure quick access to the required components. Vertical or angled? The tried-and-tested profile plate is securely attached to the stable frame profile. This means that the incline of the profile plate can be infinitely adjusted, up to the horizontal. The exercises can thus always be carried out in an ergonomic position.
9 → www.festo.com/didactic 1 2 3 Workstation Systems > Universal Laboratory Furniture > Learnline Conquer the third dimension: profile columns as an add-on surface Use the versatile profile columns as a setup space, compatible with Quick-Fix, for equipment sets or for attaching additional components vertically. Other components, such as cylinders with a 400 mm stroke, can be attached horizontally to the angled profile. Perfect use of space Thanks to the ability to tilt the profile plate, it can be lowered to a horizontal position. The free space can then be used for A4 or ER mounting frames. Training in pneumatics and electrical engineering In addition to the 700 mm profile plate, additional mounting frames can be used for electrical components. Connect ergonomically The supply duct makes all the important interfaces accessible. Not only the electrical and pneumatic supply, but also PC interfaces, such as USB, Ethernet, or serial interfaces can be integrated in the supply duct. 1 With 1100 x 700 mm profile plate and ER frame 539023 2 With 700 x 700 mm profile plate and ER frame 539025 3 Learnline with energy supply channel On request The attractively priced preferred variants. Flexible extension options. (External dimensions (W x D x H): 1512 x 780 x 1718 mm) 9
10 24-month Festo Didactic warranty Your Individual Design Basic units Stable and with a high-quality coating, the basic units are guaranteed to meet your high requirements. 1 Basic mobile unit With rollers and wheel brakes. The high worktop enables comfortable working while standing. The flexible design means this workstation is especially suitable for simultaneous 1 2 Workstation Systems > Universal Laboratory Furniture > Learnline 3 4 7 6 5 8 use on two sides. W x D x H: 1556 x 780 x 815 mm. 2 Basic stationary unit The height of the worktop makes it comfortable to work while seated. It can be used for a mounting frame to set up a profile plate. W x D x H: 1512 x 780 x 760 mm. 1 Basic mobile unit 535832 2 Basic stationary unit 535835 Drawer units 3/4/5 Fixed drawer unit for mounting in mobile workstations Fixed drawer unit with lockable steel drawers with full extension and pull-out stop. Each drawer has a load capacity of up to 20 kg and can be labeled. External dimensions W x D x H: 476 x 788 x 592 mm, usable internal dimensions W x D: 375 x 700 mm 6/7/8 Wheeled drawer unit for stationary workstations Wheeled drawer unit with lockable steel drawers with full extension and pull-out stop. Each drawer has a load capacity of up to 20 kg and can be labeled. External dimensions W x D x H: 476 x 788 x 657 mm, usable internal dimensions W x D: 375 x 700 mm. All wheels can be moved freely, two wheels have a parking brake 3 Fixed drawer unit for pneumatics (4 drawers) 535833 4 Fixed drawer unit for hydraulics (3 drawers) 539026 5 Fixed drawer unit for mobile hydraulics (2 drawers) 574153 6 Wheeled drawer unit for pneumatics (4 drawers) 535834 7 Wheeled drawer unit for hydraulics (3 drawers) 539731 8 Wheeled drawer unit for mobile hydraulics (2 drawers) 574152
11 → www.festo.com/didactic Workstation Systems > Universal Laboratory Furniture > Learnline 1 2 Mounting frames/mounting sets Versatile profile columns are the core of the Learnline structure. They are used to attach the profile plate support, to mount components, or to provide an alternative mounting surface for your training components. 1 For vertical profile plate mounting The profile plate support is mounted between the profile columns, the profile plate is firmly screwed to the mounting frame and the frame construction. The workstation is thus extremely strong and resilient, and the profile plate can be used on both sides. 2 For adjustable, inclined profile plate mounting The profile plate holder can be mounted at any height on the two profile columns, allowing you to customize the workplace ergonomics to your needs. You also have the option of attaching the components from the training package directly to the mounting frame, which will give you additional work space 3 Mounting frame for A4 mounting A4 mountings are mounted between the profile columns. Up to three rows of A4 mountings can be attached using two additional mounting sets. In order to mount the profile plates, order one mounting set per profile plate. For mounting A4 units, order one mounting set for each additional row. 1 Mounting frame for vertical profile plate mounting 540698 Mounting set for vertical profile plate mounting 540697 2 Mounting frame for inclined profile plate mounting 539032 Mounting set for inclined profile plate mounting 539735 3 Mounting frame for A4 mounting 8066141 Mounting set for A4 mounting 8065498 3 5 4 4/5 Aluminum profile plates The basis for the components of all training packages is the anodized aluminum profile plate. The slots on the front and back of the plate allow it to be used on both sides, if necessary. The slots are compatible with the ITEM profile system, grid dimension 50 mm. The components can be securely fastened in them. We recommend using the relevant rubber feet (order no. 158343) when installing the plates on a table. 700 x 550 mm 159409 4 700 x 700 mm 159410 5 700 x 1100 mm 159411
12 24-month Festo Didactic warranty Workstation Systems > Universal Laboratory Furniture > Learnline Your Individual Design 1/3 Mounting frame (1500 mm wide) The height of the ER mounting frame mounted on the profile column can be adjusted and holds up to 12 ER/6 A4 units. A mounting frame can be attached to each side of the mobile workstation. 2/4 Mounting frame (700 mm wide) The small ER mounting frame allows you to use ER/A4 components directly to the left or right of a 700 mm wide profile plate. ER and A4 mounting frames The mounting frames of the workstations can be used for a large number of exercise boards and ER units of the automation technology learning system. This compatibility also applies to the electrical engineering equipment in A4 format. This provides ample choice to create a satisfactory solution for almost any specific exercise. 1 2 4 3 1 ER mounting frame (1500 mm wide) 539022 2 ER mounting frame (700 mm wide) 539033 3 A4 mounting frame (1500 mm wide) 539021 4 A4 mounting frame (700 mm wide) 539755 5 6 7 5 Oil spillage/protective mat Black, with rubber rim. Protects the Learnline table top and keeps it clean 312 x 1512 mm 541133 6 Storage plate Fits, in addition to two drawer units, in the mobile base frame and offers storage space for two compressors (order no. 91030). W x D x H: 748 x 403 x 30 mm. Order no. 539729 7 Table extension For easy mounting to the profile column support of a mobile workstation. The table height can be adjusted between 700 and 815 mm. Table surface dimensions W x D: 780 x 600 mm Order no. 566435
13 → www.festo.com/didactic Accessories Workstation Systems > Universal Laboratory Furniture > Learnline 1 2 4 6 5 3 1 Universal bracket Enables the mounting of up to two hydraulic power packs with a single pump or up to two hydraulic discharge measuring receptacles or tubing holders. W x D x H: 50 x 275 x 130 mm. Order no. 539736 2 Tubing holder For up to 20 hydraulic tubes. Keeps the couplings tidy and protects them from dirt. W x D x H: 366 x 182 x 80 mm. Order no. 539737 3 Cable guide For one set of electrical laboratory cables. Ensures neatness and order. W x D x H: 150 x 136 x 63 mm. Order no. 535812 4 Monitor mounting bracket, short Monitor mounting bracket for TFT and LCD monitors with drilled holes according to the VESA standard (75 x 75 mm or 100 x 100 mm hole spacing). – Short articulated arm for minimum distance to the mounting surface (approx. 80 mm) – For mounting on the Learnline mounting frame or on a wall – Pivots up to 180°, tilts up to 45° – Complete with mounting materials – Maximum load capacity: 23 kg Order no. 556292 5 Monitor mounting bracket, long Monitor mounting bracket for TFT and LCD monitors with drilled holes according to the VESA standard (75 x 75 mm or 100 x 100 mm hole spacing) – Long telescopic articulated arm for large swivel angle – Distance to the mounting surface (approx. 80 - 380 mm) – For mounting on the Learnline mounting frame or on a wall – Pivots up to 180°, tilts up to 45° – Complete with mounting materials – Maximum load capacity: 15 kg Order no. 556293 6/7/8 Protective grounding for laboratory furniture The products are used as protective grounding for laboratory furniture as per the VDE 0100 standard. This is achieved by connecting touchable, conductive parts with equipotential bonding conductors to each other and connecting them to the protective conductor of the power supply. 6 Grounding set A grounding set is required for connecting all conductive parts of one to two pieces of laboratory furniture. The connector for the PE conductor of the power supply is included. Order no. 8049368 7 Connector set A connector set is required for connecting laboratory furniture to the PE conductor of the power supply. Order no. 8049447 8 Barbed T-connector for PE conductor A barbed T-connector lets you combine up to three PE conductors for connection to the power supply. Order no. 8049442 7 8
14 24-month Festo Didactic warranty Learntop-A/Learntop-L The Low-Cost Desktop Mounting System The affordable introduction to the world of training packages from Festo Didactic. Make the most of the advantages that the profile plate and the ER mounting frame can offer for your pneumatics, sensor, or PLC training. The equipment can be clearly arranged and enable work on the existing work tables and workbenches to be carried out ergonomically. Mounting materials for fitting the profile plates and assembly instructions are included in the scope of delivery. The screw fitting with the work table is recommended for safety reasons. Workstation Systems > Universal Laboratory Furniture > Learntop 1 Learntop-A An equipment carrier that can be used on one side. The components are ergonomically positioned thanks to the angled profile plate. Not suitable for hydraulics training. Supports up to two profile plates of size 350 x 1100 mm (order no. 162360) or one profile plate 700 x 1100 mm (order no. 159411). Supplied without profile plates. Order no. 540670 2 Learntop-L Equipment carrier that can be used on one side, for profile plates sized 700 x 1100 mm (order no. 159411). For horizontal placement of the profile plate. Not suitable for hydraulics training. Supplied without profile plates. Order no. 540669 1 2
15 → www.festo.com/didactic Learntop-A/Learntop-L Accessories 1 3 4 5 2 6 Workstation Systems > Universal Laboratory Furniture > Learntop 1 Aluminum profile plate The basis for the components of all training packages is the anodized aluminum profile plate. The slots on the front and back of the plate allow it to be used on both sides, if necessary. The slots are compatible with the ITEM profile system, grid dimension 50 mm. The components can be securely fastened in them. We recommend using the relevant rubber feet (order no. 158343) when installing the plates on a table. The 350 x 1100 mm size is supplied without side cover caps (H x W) 350 x 1100 mm 162360 700 x 1100 mm 159411 2 Mounting kit for hydraulic cylinder with weight To be mounted on Learnline with a vertical or horizontal profile plate (alternatively for mounting on the Learnline profile column) or Learntop-S with an inclined profile plate. With this mounting kit, the pulling and pushing load of the basic hydraulics packages, which comprise the cylinder (order no. 152857) and weight (order no. 152972), can be achieved. The cover (order no. 152973) must be used as a protective measure. Similar to the illustration! Learnline, vertical profile plate Order no. 533528 Horizontal profile plate (e.g., Learntop-L) Order no. 119352 3 Slotted mounting plate All components with the Quick-Fix quick fastening system can be attached to the slotted mounting plates. The slotted mounting plates with elastic buffers can be used lying on a table. Order no. 159331 can also be inserted into conventional A4 mounting frames. The slotted mounting plates are not suitable for use with actuators. (External dimensions: H x W in each case) 694 x 297 mm 159331 700 x 550 mm 544246 4 Rubber feet For non-slip and gentle placement of aluminum profile plates on any table surface. Set (4 pieces). Order no. 158343 5 Plug-in adapter set With the plug-in adapter set, the ER units can be attached directly to the blue plug-in panel or to the aluminum profile plate. One set is required to attach each unit Order no. 541122 6 A4 ER mounting frame The ER mounting plate can be hooked into any A4 mounting frame. A recess allows the mounting of 2 large or 4 small Festo Didactic ER units (H x W) 297 x 500 mm 536200
16 24-month Festo Didactic warranty Learntop-S The Low-Cost Desktop Mounting System The affordable introduction to the world of training packages from Festo Didactic. Make the most of the advantages that the profile plate and the ER mounting frame can offer for your pneumatics, sensor, or PLC training. The equipment can be clearly arranged and enable work on the existing work tables and workbenches to be carried out ergonomically. Mounting materials for fitting the profile plates and assembly instructions are included in the scope of delivery. The screw fitting with the work table is recommended for safety reasons. Workstation Systems > Universal Laboratory Furniture > Learntop 1 Learntop-S The flexible equipment carrier for all technologies, with ER mounting frame. – Mobile: Can simply be set up on an existing work table or workbench. – Versatile: Can be used on both sides. – Ergonomic: The angled profile plate allows the components to be clearly arranged. – Dimensions (W x D x H): 1110 x 525 x 980 mm Supports up to 4 profile plates of size 350 x 1100 mm (order no. 162360) or 2 profile plates 700 x 1100 mm (order no. 159411). Supports up to 2 profile plates of size 350 x 1100 mm (order no. 162360) and 2 slotted mounting plates (order no. 8062676) for Learntop-S for Quick-Fix clamping piece mounting, one of them on each side Supplied without profile plates. Order no. 8062672 2 Mobile worktable for Learntop-S – Drawer unit with 8 fully extending drawers, load per drawer up to 20 kg – Storage space with lockable sliding doors – Tubular steel table top – Dimensions (W x D x H): 1118 x 778 x 920 mm – Table height: 920 mm Order no. 8062673 2 1+2 1
17 → www.festo.com/didactic Learntop-S Accessories 1 3 4 5 7 6 Workstation Systems > Universal Laboratory Furniture > Learntop 1 Aluminum profile plate The basis for the components of all training packages is the anodized aluminum profile plate. The slots on the front and back of the plate allow it to be used on both sides, if necessary. The slots are compatible with the ITEM profile system, grid dimension 50 mm. The components can be securely fastened in them. We recommend using the relevant rubber feet (order no. 158343) when installing the plates on a table. The 350 x 1100 mm size is supplied without side cover caps (H x W) 350 x 1100 mm 162360 700 x 1100 mm 159411 2 Perforated work surface For Lab-Volt series pneumatic/ hydraulic learning system, 700 x 1100 mm for Learntop-S (only compatible with Learntop-S) Order no. 8062675 3 Slotted mounting plate For installing Quick-Fix clamping pieces, must be used together with an aluminum profile plate 350 x 1100 mm (order no. 162360) so that Quick-Fix screw connection components can also be attached (only compatible with Learntop-S order no. 8062672). Order no. 8062676 4 Cable guide For one set of electrical laboratory cables. Ensures neatness and order. W x D x H: 150 x 136 x 63 mm. Order no. 535812 5 Tubing holder For up to 20 hydraulic tubes. Keeps the couplings tidy and protects them from dirt. W x D x H: 366 x 182 x 80 mm. Order no. 539737 6 Steel tub base for Learntop-S Order no. 8062674 7 Mounting kit for hydraulic cylinder with weight To be mounted on Learnline with a vertical or horizontal profile plate (alternatively for mounting on the Learnline profile column) or Learntop-S with an inclined profile plate. With this mounting kit, the pulling and pushing load of the basic hydraulics packages, which comprise the cylinder (order no. 152857) and weight (order no. 152972), can be achieved. The cover (order no. 152973) must be used as a protective measure Learntop-S, inclined profile plate Order no. 526847 2
